2024 T3 Aerospace Grade Aluminum Alloy Sheet Plate 1.5mm-150mm Thickness for Aircraft Structural Components
| उत्पत्ति के प्लेस | शेडोंग, चीन |
|---|---|
| ब्रांड नाम | Hongtu |
| प्रमाणन | ISO 9001:2015, SGS, AMS-QQ-A-250/4 |
| मॉडल संख्या | 2024-T3 |
| न्यूनतम आदेश मात्रा | 500 किलोग्राम |
| मूल्य | USD 3.5-5.8 / kg |
| पैकेजिंग विवरण | एंटी-रस्ट पेपर इंटरलीव्ड, स्टील स्ट्रैपिंग के साथ निर्यात-ग्रेड लकड़ी का फूस, नमी-प्रूफ पीई फिल्म रै |
| प्रसव के समय | स्टॉक के लिए 5-7 कार्य दिवस, उत्पादन के लिए 15-25 दिन |
| भुगतान शर्तें | टी/टी, एल/सी, पेपैल, वेस्टर्न यूनियन |
| आपूर्ति की क्षमता | 2000 टन प्रति माह |
उत्पाद विवरण
| मिश्र धातु | 2024 | गुस्सा | टी3, टी351, टी4 |
|---|---|---|---|
| मोटाई | 1.5 मिमी - 150 मिमी | चौड़ाई | 1000 मिमी, 1250 मिमी, 1500 मिमी, 2000 मिमी, 2500 मिमी |
| लंबाई | 2000 मिमी, 2440 मिमी, 3000 मिमी, 6000 मिमी या अनुकूलित | मानक | एएसटीएम बी209, एएमएस 4035, एएमएस 4037, एन 573 |
| सतही समापन | मिल फ़िनिश, एनोडाइज़्ड, लेपित, पॉलिश | तन्यता ताकत | ≥ 485 एमपीए |
| नम्य होने की क्षमता | ≥ 345 एमपीए | बढ़ाव | ≥ 12% |
| आवेदन | विमान संरचनाएं, धड़, विंग स्पार्स, उपकरण | ||
| प्रमुखता देना | 2024 T3 Aerospace Aluminum Sheet,Aircraft Grade Alloy Plate 2024,High Strength Aviation Aluminum Plate |
||
उत्पाद विवरण
2024 T3 Aerospace Grade Aluminum Alloy Sheet Plate 1.5mm-150mm Thickness for Aircraft Structural Components
2024 T3 Aerospace Grade Aluminum Alloy Sheet Plate
The 2024 T3 aluminum alloy sheet is a high-strength, heat-treatable alloy renowned for its excellent strength-to-weight ratio and superior fatigue resistance. Widely used in aerospace and aviation industries, this alloy delivers reliable performance in demanding structural applications.
Key Features
- High Strength: Tensile strength ≥ 485 MPa in T3 temper, rivaling mild steel strength with 1/3 the weight
- Excellent Fatigue Resistance: Engineered to withstand repeated stress cycles in aircraft applications
- Good Machinability: Superior cutting and forming characteristics for complex component manufacturing
- Heat Treatable: Solution heat-treated and cold-worked for enhanced mechanical properties
- Natural Aging: Stable mechanical properties achieved through natural aging process
Chemical Composition (Weight %)
| Element | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Al |
|---|---|---|---|---|---|---|---|---|---|
| Min | - | - | 3.8 | 0.3 | 1.2 | - | - | - | Remainder |
| Max | 0.50 | 0.50 | 4.9 | 0.9 | 1.8 | 0.10 | 0.25 | 0.15 |
Mechanical Properties (T3 Temper)
| Property | Value |
|---|---|
| Tensile Strength | ≥ 485 MPa |
| Yield Strength | ≥ 345 MPa |
| Elongation | ≥ 12% |
| Hardness (Brinell) | 120 HB |
| Density | 2.78 g/cm³ |
Available Dimensions
| Parameter | Range |
|---|---|
| Thickness | 1.5mm - 150mm |
| Width | 1000mm - 2500mm |
| Length | 2000mm - 6000mm or Custom |
| Temper | T3, T351, T4, T42 |
Applications
- Aircraft fuselage skins and structural panels
- Wing spars, ribs and stringers
- Vehicle armor plates
- High-performance truck wheels
- Precision machined components and fittings
Our Advantages
- Strict Quality Control: Every batch undergoes spectrographic analysis, tensile testing and ultrasonic inspection
- Complete Traceability: Mill test certificates (MTC EN 10204 3.1) provided with every shipment
- Flexible MOQ: Small trial orders accepted from 500 kg
- Professional Packaging: Export-grade wooden pallets with anti-corrosion paper and PE film wrapping
- Fast Delivery: Extensive stock inventory for prompt shipment; custom production within 15-25 days
Contact us today for a competitive quotation, free sample cutting, and technical consultation on 2024 T3 aerospace aluminum sheets.
